40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges

40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges

  • 40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
  • 40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
  • 40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
  • 40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
  • 40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
  • 40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges
Product Details:
Place of Origin: China
Certification: SGS/CE/ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 10-49 Pieces
Price: $65.00
Payment Terms: T/T L/C West Union
Supply Ability: 500 Piece/Pieces per Day
Contact Now
Detailed Product Description
Name: Pleated Polypropylene Folded Filter Filter Membrane Material: PP/Fiberglass
Length: 10/20/30/40/50/60 Inch Conector: DOE/SOE/Customized
Micron: 1/3/5/10/25/50/75/100/150 O-ring Material: EPDM/Silicone/PTFE
Sealing Method: Hot Melting Welding Diameter: 165mm/OEM
Inner Core: PP MOQ: Currently No Limited
Selling Units: Single Item Single Package Size : 155X40X40 Cm
Single Gross Weight: 45.000 Kg
High Light:

40Inch High Flow Filter Cartridges

,

30'' pleated polypropylene filter cartridge

,

5 Microns pp spun filter cartridge

Big flow PP 10/20/30/40 inch 5 microns pleated pp spun cartridge filter for ro plant

The high flow replacement filter cartridge series designed to be used in the different filter housings which contains 1-37 filter cartridges. It can be used for different flow rate request. The large diameter with big filter area insures to reduce the number of filter cartridges and the dimension of housing required. This filter cartridges has various applications on water treatment system. Higher dirt holding capacity and longer service life with further specifications of the large industrial water plant projects.
Most of the raw materials are imported from abroad.Pleated filter element is a kind of deep filtration filter,it is usuaslly used as liquid overheating,clarification, filtration and terminal filter.


Product Name
Big flow PP 10/20/30/40 inch 5 microns pleated polypropylene folded filter for industrial RO pre water plant



Filtration media
Polypropylene membrane & Fiberglass membrane


Support material
Polypropylene


Core & Structural components
Polypropylene


 Inner core
Polypropylene


Packing method
Polybag with single box


Filtration precision
1μm, 2μm, 3μm, 5μm, 10μm, 20μm, 25μm, 30μm, 50μm


Length
10", 20", 30", 40", 50", 60", Customized


Adaptor
SOE/DOE


Sealing method
Hot melting welding


Sealing gasket & O-ring material
Silicone/EPDM/VITON/PTFE/NBR


Filter cartridge diameter
165mm


Max. working temperature
Pleated polypropylene: 82℃
Pleated fiberglass: 121℃
Melt blown: 65℃


Applications
Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;







Features

All contaminants can be removed within the cartridges because of the flow direction. Up to 110m³/h flow rate per one filter cartridge for water filtration. Max. 50% reduction of filter system. Multi membrane layers for large dirt holding in the high flow filter elements. Thermally bonded construction for stronger pressure resistance. Handle design quick installation, safe and reduce the cost.

40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges 0
40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges 1



General Description

The LY-HFM filter cartridge series designed to be used in the different filter housings which contains 1-37 filter cartridges. It can be used for different flow rate request. The large diameter with big filter area insures to reduce the number of filter cartridges and the dimension of housing required. This filter cartridges has various applications on water treatment system. Higher dirt holding capacity and longer service life with further specifications of the large industrial water plant projects.

40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges 2

General Description

The LY-HFMH filter cartridge series designed to be used in the different filter housings which contains 1-37 filter cartridges.The LY-HFPM series high flow filter cartridge is the horizontal pleated big flow water filter cartridge.It can be used for different flow rate request. The large diameter with big filter area insures to reduce the number of filter cartridges and the dimension of housing required. This filter cartridges has various applications on water treatment system. Higher dirt holding capacity and longer service life with further specifications of the large industrial water plant projects.
40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges 3

General Description

The LY-HFPK filter cartridge series is a replacement cartridges for the depth filtration and 2-1/2” diameter cartridges for the high flow applications. Pre-filtration for RO system is an example.The Lvyuan filter pleated design with high flow area and contamination removal capacity. This design helps end user to reduce capital investment, save space, and easy to change-out and etc. Up to 1300LPM flow rate per filter cartridge reduced the number of filter cartridges and the dimension of the filter housing required. Water treatment volume per super-high flow filter cartridge equals to 10x40” length, 2-1/2” diameter filter cartridges. Inner O-ring insures no by pass and handle design makes the installation easier.
40 Inch 5 Microns Pleated PP Spun High Flow Filter Cartridges 4
