Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns

Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns

  • Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
  • Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
  • Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
  • Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
  • Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
  • Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
Industrial SS304 Basket Type Filter High Pressure Water Pre Filtration Stainless Steel Bag Cartridge 32 Inch 5 Microns
Product Details:
Place of Origin: Guangdong, China
Brand Name: LVYUAN/OEM
Payment & Shipping Terms:
Minimum Order Quantity: 10 - 499 Pieces
Price: $5.00
Packaging Details: High pressure stainless steel bag cartridge 32 inch SS304 basket type filter for water pre filtration 5 microns:10" 50PCS/CTN, 20" 25PCS/CTN, 30" 25PCS/CTN, 40" 25PCS/CTN.
Contact Now
Detailed Product Description
Core Components: Pressure Vessel Warranty: 1 Year
After-sales Service Provided: Online Support Name: Bag Cartridge Water Filter
Filter Membrane Material: Polypropylene/Pleated Length: 16"/32"/Customized
Conector Material: Polypropylene Micron: 1 ~ 100um
O-ring Material: EPDM/Silicone/NBR Bag Cartridge Filter Size: #1 #2
Sealing Method: All-in-One Diameter: 6"/Customized
MOQ: Currently No Limited
High Light:

SS304 Basket Type Filter

,

5 Microns Basket Type Filter

Industrial high pressure water pre filtration stainless steel bag cartridge 32 inch 5 microns SS304 basket type filter

Product Description


Product Name:
High pressure stainless steel bag cartridge 32 inch SS304 basket type filter for water pre filtration 5 microns



Stainless steel filter housing:
Bag filter cartridge type



Length:
16", 32"



OD:
6"



Filter membrane media:
Polypropylene PP pleaated



Seal Material:
EPDM, Silicone, NBR, Viton



Filter handle:
Adjustable Polypropylene PP



End cap material:
Polypropylene PP



Center core:
Polypropylene PP



Outer cage:
Polypropylene PP



Microns rating:
1um, 2um, 3um, 5um, 10um, 20um, 25um, 30um, 50um, 75um,100um



Operating pressure:
Max. operating temperature: 64℃;
Maximum pressure drop: 3.4bar, 60℃;
Recommended pressure for replaced filters: 2.4bar, 20℃



Service condictions:
3.5 bar at 65℃;



Applications:
RO water treatment prefiltration;
Electronic;
Oil & Gas liquid;
Petroleum industry.



MOQ
1pcs/Box, 4boxes/Carton




High pressure stainless steel bag cartridge 32 inch SS304 basket type filter for water pre filtration 5 microns:

Guangzhou Lvyuan Water Purification Equipment Co., Ltd., we manufacture in a wide range of sizes and microns options filter elements and fits to different specification of filter housings. This type of pleated cartridge filter has superior flow characteristics with very low pressure drop compared to depth media of similar microns rating. It has large filtration area and design, allow the use of a reduced number of cartridges, high dirtholding capacity and long lifetime. Fully thermal welded construction can be used safely on high temperature oily water, solvents, acid and diesel.

Features:

1. To fit into different standard sizes stainless steel bag water filter cartridge housing.
2. High dirtholding capacity and high flow rate.
3. Large capacity filtration area and depth filtration provides a long lifetime of pleated cartridge water filter.
4. Low filter cartridges replacement cost, because of the large filter area to reduce labor costs to change.
5. The filter can be used safely on the liquid water, diesel, oily liquid, chemical solvents, acid and alkali.
