222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter

222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter

  • 222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
  • 222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
  • 222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
  • 222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
  • 222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
  • 222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter
Product Details:
Place of Origin: Guangdong, China
Brand Name: Lvyuan / OEM
Certification: SGS/CE/ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: $12.00 / Piece
Payment Terms: T/T L/C West Union
Supply Ability: 500 Piece/Pieces per Day
Contact Now
Detailed Product Description
Material: Polypropylene Weight: Depends
Size: Standard Or Customization Product Name: Polypropylene Pp Cartridge Filter
Micron Rate: 1/3/5/10/25/50/75/100 Micron Filters Cartridge Application: Water Filter Parts, Reverse Osmosis
Length: 5", 10", 20", 30", 40", 50'' Inch Filter Media: Polypropylene PP Spun
End Cap: DOE/222Fin/226Fin/222Flat/226Flat Gasket/O Ring Material: Silicon/EPDM/Viton
Usage: Liquid Cartridge Filter Inner Core: PP, Stainless Steel, None
Selling Units: Single Item Single Gross Weight: 3.000 Kg
High Light:

SWRO PP Sediment Cartridge Filter

,

222 FIN pp meltblown filter

,

4.5" PP Sediment Cartridge Filter

Big diameter Spun Meltblown PP Cartridge SWRO High Flow Cartridge Filter with Self Core Design


Product Description

The PP melt-blown filter core is made of polypropylene resin, and is formed by winding of fibers themselves. The structure of the PP melt-blown filter is thick in the outer layer, the inner layer is thin, the outer layer is loose, and the inner layer is tightly tapered to gradually tighten. Filtered from the outer to the inner level, the closer to the inner layer of the filter, the smaller the aperture and the higher the precision of the filtration.

Specification

100% polypropylene
High dirt holding capacity Depth filtration, high dirt holding capacity
Many connections are Cut Ends; 226/FIN; 222/FIN
available
Wide Chemical compatability Can be used in the solvent which PH value is from 1 to 13
Effective Filtration Area 0.40M2 per 10"
Materials Filter Media: Polypropylene / Cotton/Glass fiber
Inner core: Polypropylene or Stainless Steel
Cartridge Dimensions Outer Diameter: 63mm (2.5") / 114mm (4.5")
(Nominal)
  Inner Diameter: 28mm (1.10")
  Length: 10"- 254mm
  20"- 508mm
  30"-762 mm
  40"- 1016mm
  * (Length is based on Cut Ends)
Cartridge Purity Free of surfactants, resins, binders and adhesives





Application


1. Drinking Water Treatment
2. Industrial water treatment, like electronic, power, plating and oil industry.
3. Pre-filtration of RO/DI system
4. Food and Beverage
5. Sea Water Desalination
6. Chemical, solvent, wine, etc.


222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter 0
222 FIN OD 4.5" SWRO PP Meltblown Sediment Cartridge Filter 1
