M20 Thread 50um Sintered Porous Micron Cartridge Filters

M20 Thread 50um Sintered Porous Micron Cartridge Filters

  • M20 Thread 50um Sintered Porous Micron Cartridge Filters
  • M20 Thread 50um Sintered Porous Micron Cartridge Filters
  • M20 Thread 50um Sintered Porous Micron Cartridge Filters
  • M20 Thread 50um Sintered Porous Micron Cartridge Filters
  • M20 Thread 50um Sintered Porous Micron Cartridge Filters
  • M20 Thread 50um Sintered Porous Micron Cartridge Filters
M20 Thread 50um Sintered Porous Micron Cartridge Filters
Product Details:
Place of Origin: Guangdong, China
Brand Name: Lvyuan/OEM
Certification: SGS/CE/ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: >=10 Pieces
Price: $25.00
Packaging Details: 50 microns stainless steel 304 316L mesh filter sinter porous metal filter tube for water/liquid/air treatment: Single packaging (inner box)
Payment Terms: T/T L/C West Union
Supply Ability: 500 Piece/Pieces per Day
Contact Now
Detailed Product Description
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Pressure Vessel Warranty: 1 Year
After-sales Service Provided: Online Support Name: Stainless Steel 304 316L Mesh Filter Sinter Porous Metal Filter Tube
Material: SS304/316L Length: 10/20/30/40/60 Inch
Micron: 1 - 300um Layers: 5 Layers
Interface Form: 222,226,215, M36, M24, M22, M20 Thread Interface Heat Resistance: - 200 -- 500 Degree
Working Pressure: 0.1 - 30Mpa Size: Customized
High Light:

Sintered Porous Micron Cartridge Filters

,

50um sintered porous metal filter

,

M20 thread SS sintered filter cartridge

50 microns stainless steel 304 316L mesh filter sinter porous metal filter tube



Sintered mesh filter series ----



Main material of the sintered mesh filter adopts standard five-layer sintered mesh,

which is made by using special process of lamination molding and vacuum sintering on five-layer

stainless wire cloth. The filter is characterized by strong corrosion resistance, fine penetrability, high strength,

easy washing and back washing, accurate filtration precision, clean filter material, solid mesh, etc.

Main connection modes are standard interface (such as 222, 220 and 226), fast interface connection, thread,

flange and pushing rod connection, special custom interface. The material has widely applied for the filtration

of polyester,water treatment, oil product, pharmacy, foods and beverage, chemical industry, chemical fiber

products and high-temperature air medium.



1.The standard five-layer mesh is composed of protective layer, precision control layer, dispersion layer,

two strengthening layers.

 2.High intensity: as the five-layer wire mesh is sintered, it is characterized by extremely high machinery

strength and compressive strength.

3. High precision: It can realize uniform surface filtration for the material with 2-200um filtration granularit.

4. Heat resistance: It can be applied for the continuous filtration under -200  ~ 500 degree centigrade.

5.Washing performance: The surface filtration structure with fine back washing effect, the washing course

is simple.







Filter cylinder series of water treatment equipment ---



This series product adopts punch plate composite sintered mesh as the filtration material,

reasonable arranges the mesh layer distribution and mesh number based on different operation conditions

and purposes. As the filter cylinder integrates the proof pressure framework with the sintered filter screen,

the product is superior to any other filtration materials in the respects of higher machinery strength, optimum

back washing effect and less pressure drop loss. Thus it has been widely applied for the intelligent washing

equipment, intelligent differential pressure water treatment equipment., food and beverage filtration equipment.

The MONEL.dual phase steel, titanium alloy and other punch plate composite sintered mesh filter cylinder

serial products manufactured by our company are highly praised and have been widely promoted and applied in fields of large scale sea water filtration treatment.



1.Punch plate material is 304 or 316L, the punch pore can be square or round;

2.It can be manufactured as different products according to different shape requirements;

3.It can be customized as different materials with different thicknesses as required by the client;

4.The MONEL, dual phase steel, titanium alloy and other punch plate composite sintered mesh can

be customized according to operation conditions.
