Microporous Sintered Plastic Filter

Microporous Sintered Plastic Filter

  • Microporous Sintered Plastic Filter
  • Microporous Sintered Plastic Filter
  • Microporous Sintered Plastic Filter
  • Microporous Sintered Plastic Filter
  • Microporous Sintered Plastic Filter
  • Microporous Sintered Plastic Filter
Microporous Sintered Plastic Filter
Product Details:
Place of Origin: Guangdong, China
Brand Name: Lvyuan / OEM
Certification: SGS/CE/ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: $0.50 - $2.00 / Piece
Payment Terms: T/T L/C West Union
Supply Ability: 500 Piece/Pieces per Day
Contact Now
Detailed Product Description
Video Outgoing-inspection: Provided Marketing Type: New Product 2020
Material: Carton Weight: Depends
Size: Customized Warranty: Unavailable
Product Name: Pp Sintering Filter Micron Rate: 0.1 To 300 Micron
Material Option (customized): PP,PE, PA, PTFE, Stainless Steel, Bronze Etc Length: OEM, 5", 10", 20", 30", 40", 50'', 60''
Stainless Steel Material: 304, 316L Interface Form: 222,226,215, M36, M24, M22, M20 Thread Interface
End: DOE, SOE, Insert, Screw Type Usage: Gas, Liquid Filtration
Working Pressure: 0.1 To 30Mpa Shape: Tube, Cup, Disc, Stick, Plate, Sheet, Etc
Core Components: Filter Accessories Selling Units: Single Item
Single Package Size : 10X10X20 Cm Single Gross Weight: 1.000 Kg
High Light:

Microporous Sintered Plastic Filter


100um microporous membrane filter


100um Sintered Plastic Filter

Micro PE Sintered Plastic Porous Polypropylene PP Sintering Filter

Sintered Plastic Filters mainly refer to PTFE, PE, PP sintered filter elements. They’re made of pure PTFE, polyethylene, polypropylene raw materials and sintered at high temperature and high pressure. Therefore, the sintered plastic filter element has strong resistance to strong acids and alkalis, and the porous plastic filter element has high strength and toughness. Filtering size from 0.2 to 100 microns, easy to clean. The inner and outer surfaces are very smooth, and fully sintered under high temperature and high pressure, there will be no "threshing" phenomenon during use and no pollution the fluid, so it is widely used in the water, air and gas filtration industries.
Product Feature
1. High porosity to ensure a greater flow per unit area; 2. Smooth outer surface, impurities are not easy adhesion, back washing easy and thorough; 3. Anti-fouling ability: the small size of the filter so that impurities can’t be retained in the filter body; 4. Resistance to strong acid, alkali corrosion, resistance to organic solvents; 5. Excellent mechanical properties; 6. No particle release. 7. Wide Product range and wide scope of application
Filter Media PE, HDPE, PTFE, PVDF, PA/Nylon etc
Micron rate 0.2um, 0.5um, 1um, 3um, 5um, 10um, 25um, 30um, 50um, 75um, 100um, etc
Reference dimension 31x12x1000, 31x20x1000, 38x20x1000, 38x18x1000, 38x20x1200, 38x20x1300, 38x20x150, 38x20x400, 38x20x250, 38x20x200, 38x20x180,
(mm) 38x20x150, 50x20x1000, 50x31x1000, 50x38x1000, 65x31x1000, 65x38x1000, 64x44x1000, 78x62x750mm, etc.
Connector type DOE, SOE, Flat, insert, thread, 226, 222, 215, M36, M30, M27, M25, M22, M14, M12, or as request.
Max. operating temperature PE≤82℃; PTFE≥200℃; PA≤120℃


Microporous Sintered Plastic Filter 0

Microporous Sintered Plastic Filter 1
