PP PTFE Pleated Filter Cartridge
Product Details:
Place of Origin: Guangdong, China
Brand Name: Lvyuan/OEM
Certification: SGS/CE/ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 10-99 Pieces
Price: $3.00
Payment Terms: T/T L/C West Union
Supply Ability: 500 Piece/Pieces per Day
Contact Now
Detailed Product Description
Machinery Test Report: Provided Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: Engine
Material: Pleated Weight: Customized
Size: Customized Power: 0
Warranty: Unavailable Name: 10 Inch Polypropylene Pleated PP Filter Cartridge
Length: 2.5 ~ 60 Inch Filter Membrane Material: PP/PVDF/PTFE/PES/Nylon
Micron: 0.01 ~ 100 Micron Pleated Filter Cartridge O-ring Material: EPDM/Viton/Silicone/PTFE
Sealing Method: Hot Melting Welding Diameter: 70mm
Max. Operating Temperature: 65℃ Fitting Code: Spear Type / 215 / 222 / 226 / DOE
Inner Core: PP/SS Material Selling Units: Single Item
Single Package Size : 30X5X5 Cm
High Light:

PP PTFE Pleated Filter Cartridge


69mm Pleated PP Filter Cartridges

10 20 30 40 inch polypropylene pleated PP filter cartridge PTFE pleated filter cartridge


Product Description

PP Pleated Filter Cartridge cater to high efficiency filtration requirement. They are constructed of high purity polypropylene materials which increasing dirt holding capacity. The materials comply with FDA related requirement.The high surface area enable high flow rates and long service life. The series of cartridge with multiple layered microporous ensure stable performance and broad chemical compatibility


Filtration medium

 PP / PTFE / PVDF / PES / Nylon

Up & Bottom flow support layer material


Support frame & Structural Components


Filtration precision




Sealing material

Silicone rubber,Nitrile butadiene rubber,

EPDM,Fluorine rubber.

Sealing method

Hot melting welding

Effect filtration area

≥0.6 m/10"

Filter cartridge diameter

69.0 mm

Maximum Working Temperature

80℃,0.17 MPa

Highest Temperature

140℃,0.27 MPa

Max positive differential pressure

0.42 MPa(25℃)

Max back pressure differential pressure

0.28 MPa(25℃)

Sterilization Conditions

121℃ 30 min

Application Field

Chemical Industry: Organic solvents,

various of alcohols, Chemical reagents

filtration,Sterile storage tank breathing

apparatus, such as fermentation tank air filter

PP PTFE Pleated Filter Cartridge 0


Product Overviews
PP PTFE Pleated Filter Cartridge 1

PP PTFE Pleated Filter Cartridge 2PP PTFE Pleated Filter Cartridge 3




 Polypropylene microporous membrane flter


Using the polypropylene composite membrane filter as the filtration material,

this filter is a kind of advanced and fixed type deep filtration filter cartridges,

the filtration micron is from 0.1um to 60um. The filtration membrane is not affected

by feed water pressure. Its unique advantages for low pressure differential, high flux,

good filtration precision, and low economic cost, it is favored by the users.


Hydrophobic PTFE filter


The filter medium is Hydrophobic PTFE microporous membrane filter: Strong hydrophobicity,

High holding rate, excellent chemical resistance and thermal stability, good strength,

impact resistance of the forward & reverse pressure.


Hydrophilic PTFE filter

The filter element medium for hydrphilic PTFE microporous membrane filter: The hydrophilic

stability, high entrapment rate, excellent chemical resistance thermal stability, good strength,

impact resistance of the forward & reverse pressure.


Nylon filter


The filter medium is hydrophilic nylon microporous membrane filter, It is composed by nylon

membrane and the polypropylene support material hot melting, it is no dung, also applicable

for the strict chemical and pharmaceutical industries.

Main features:Hydrophilic stability, strong flexibility, high entrapment rate, excellent chemical

resistance, especially suitable for filtering of the organic solvent. Forward and reverse pressure

shock resistance.



PP PTFE Pleated Filter Cartridge 4PP PTFE Pleated Filter Cartridge 5
