Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges

Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges

  • Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
  • Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
  • Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
  • Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
  • Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
  • Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges
Product Details:
Place of Origin: Guangdong, China
Brand Name: Lvyuan,OEM,ODM
Certification: SGS/CE/ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1-9 Pieces
Price: $515.00
Packaging Details: paper box and wooden case
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Piece/Pieces per Year
Contact Now
Detailed Product Description
Warranty Of Core Components: 1 Year Core Components: Pressure Vessel
Material: Stainless Steel Weight: Customized
Size: Customized, 10''20''30''40'' Warranty: 1 Year
After-sales Service Provided: Online Support Feature: Liquid Purify
Shape: Cylinder Connector Type: Clamp
Application: Industry Water Surface: Polished/mirror
Name: Sanitary Filter Housing Raw Material: Stainless Steel
Color: Silver Selling Units: Single Item
Single Package Size : 80X40X40 Cm Single Gross Weight: 28.000 Kg
High Light:

0.3um sanitary filter housing

,

0.3um 20 Inch Water Filter Cartridges

,

M6 Thread water filter cartridges

Sterile Sanitary Stainless Steel Single Cartridge Filter Housing ss304 ss316 for Water Treatment



Feature



• Ultra high level of polishing, use 0.3um, the outer wall is 0.4um, absolute health level and polishing.
• Using strong fast loading, the highest pressure of 0.6 Mpa, 1.0 Mpa.
• Low exhaust valve and drain valve: threaded joint sets and pagoda from, when deflated and drainage, with the connect lose won't turn.
• Low filter supporting feet by strengthening thread, not easy sliding teeth, more durable; Can be installed adjusting nut at the bottom of the feet, can adjust the height of the filter, easy to use.




Operating Conditions
Max. operating pressure 0.6MPa 1.0MPa
Max. operating temperture 150℃
Disinfect Online or steam sterilization: 121℃/30min
Material
Shell 304, 316L
Eyebolt 304
Stabilizer blade 304
O-ring EPDM, PTFE Viton, Silicone
Connection
Connection of shell Tri-clamp
N1, N2 In- outlet Tri-clamp
N3 Pressure gauge(option)
1.5″Tri-clamp

N4vent valve(option) M6 Thread
N5 Drain valve (option) M6 Thread
Cartridges connection 222 type, 226 type
Surface Finish
Finish type Mechanical / electrolytic polishing, sand blasting
Polishing precision 0.3um Inner surface Ra≤0.3um
0.4um Outside surface Ra≤0.4um



Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges 0



GENERAL DESCRIPTION

It consists of a stainless steel housing and filter elements. The filter housing is made of high-quality stainless steel. It is quick-opening, and clamp type replacement filter doesn't require tools. It is convenient and quick.

The filter element adopts different materials such as pleated filter cartridge as the replacement cartridges to remove tiny suspended, bacteria and other impurities in the water; the filter medium enters the housing body from the outside, is filtered through the filter element, and the liquid is discharged from the bottom, and the filter residue is blown back or compressed by compressed air. The liquid is mixed and blown back.



Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges 1
Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges 2


Different stainless steel multi-cartridges filter housing are customized, as long as you offer us picture and drawing.

Any request will be respond within 20 hours.



Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges 3
Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges 4
Sanitary M6 Thread 0.3um 20 Inch Water Filter Cartridges 5


Application

 Widely used in fine chemicals, pharmaceutical, textile, chemical, metallurgy, machinery, electroplating and other industries.

It can filter out liquids and gases above 0.1um particles and bacteria, it has high filtration precision, fast transition speed, less adsorption, no The advantages of medium separation, acid and alkali corrosion resistance, and convenient operation.
