| Place of Origin: | Guangdong, China |
| Brand Name: | Lvyuan/OEM |
| Certification: | SGS/CE/ISO 9001 |
| Minimum Order Quantity: | 1 Piece/Pieces |
|---|---|
| Price: | $7.00 - $151.00 / Piece |
| Packaging Details: | 0.2 0.45 1 5 micron stainless steel beer filter cartridge element for beer filter machine Single packaging (inner box) |
| Payment Terms: | T/T L/C West Union |
| Supply Ability: | 500 Piece/Pieces per Day |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
|---|---|---|---|
| Warranty Of Core Components: | 1 Year | Core Components: | Pressure Vessel |
| Warranty: | 1 Year | After-sales Service Provided: | Online Support |
| Product Name: | Stainless Steel Filter Element | Micron Rate: | 0.1 To 300 Micron |
| OEM Dimension: | Available | Length: | 5", 10", 20", 30", 40", 50'', 60'' Inch |
| Stainless Steel Material: | 304, 316, 316L | Interface Form: | 222,226,215, M36, M24, M22, M20 Thread Interface |
| Layer: | Pleated/mesh Cartridge Filter | Usage: | Gas, Liquid Filtration |
| Heat Resistence: | - 200 -- 500 Degree | Working Pressure: | 0.1 To 30Mpa |
| High Light: | 0.45 Micron Sintered Metal Cartridge Filter,500mm Sintered Metal Cartridge Filter,0.2 Micron sintered porous metal filter |
||
Sintered mesh inline and pressure filter element is placed in the precessing line to filtrate the processing liquid, often oil, to protect the downstream equipment from impurity and other particles. Sintered wire mesh filter can withstand high pressure and temperature, thus can be backwahsed / backflushed and gain longer service life than synthetic fiber filters.
|
Model
|
Nominal rating(μm)
|
up tp 1micron
|
|
|
Classification
|
Cylindrical filter cartridge / filter tube
|
Outer diameter(mm)
|
65
|
|
Filter Media
|
Stainless steel sintered wire mesh
|
Length(mm)
|
500
|
|
Material
|
316L stainless steel
|
Connector / End fitting
|
226/222/DOE/thread
|
|
Application
|
Filtration separation aeration
|
||
1. Excellent mechanical strength.
2. High dirt holding capacity.
3. High pressure resistance, withstand capacity and low pressure drop.
4. Temperature ratings from -73°C to 480°C.
5. Various micron ratings available from 2um to 1000um nominal.
6. Back flushing and cleanable for long service life.
7. Strong corrosion resistant for wide chemical compatibility.
8. High permeability, no media migration.
9. Customized dimension are welcome.
