| Place of Origin: | Guangdong, China |
| Brand Name: | Lvyuan/OEM |
| Certification: | SGS/CE/ISO 9001 |
| Minimum Order Quantity: | 1 Piece/Pieces |
|---|---|
| Price: | $30.00 - $151.00 / Piece |
| Packaging Details: | Reusable 0.2/0.45/1/5/10 um micron Sintered Stainless Steel SS 316L Powder Filter Cartridge Single packaging (inner box) |
| Payment Terms: | T/T L/C West Union |
| Supply Ability: | 500 Piece/Pieces per Day |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
|---|---|---|---|
| Warranty Of Core Components: | 1 Year | Core Components: | Pressure Vessel |
| Warranty: | 1 Year | After-sales Service Provided: | Online Support |
| Product Name: | Stainless 316L Filter Cartridge | Micron Rate: | 0.1 To 300 Micron |
| OEM Dimension: | Available | Length: | 5", 10", 20", 30", 40", 50'', 60'' Inch |
| Stainless Steel Material: | 304, 316, 316L | Interface Form: | 222,226,215, M36, M24, M22, M20 Thread Interface |
| Layer: | Pleated/mesh Cartridge Filter | Usage: | Gas, Liquid Filtration |
| Heat Resistence: | - 200 -- 500 Degree | Working Pressure: | 0.1 To 30Mpa |
| High Light: | SS316L Sintered Metal Cartridge Filter,30mm ss sintered filter cartridge,Lvyuan Sintered Metal Cartridge Filter |
||
Non-standard Stainless steel filter cartridge specifications (special size, shape, connection, etc) can be customized according to customer's requirement.
| Fiter Cartridge dimensions | |
| Length | 5'' (125mm), 10'' (250mm), 20'' (500mm), 30'' (750mm), 40'' (1000mm) |
| Diameter | Ø25, 30, 50, 60, 65, 70mm |
| Other dimensions | Customized by customer's request. |
| Material of constructions | |
| Filter media | SUS304, 316, 316L stainless steel |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, SOE, 215, 222, 226, M20, M30, M42, 1'' NPT/BSP or as request. |
| Outside protection net | Optional |
| Sealing material | Silicone, NBR, EPDM, Buna, Teflon, etc |
| Performance | |
| Removal rate | 1, 3, 5, 10,20, 30, 40, 50, 100um, etc |
| Effective Surface area | 0.65sqm per 10" cartridge element |
| Operation Temperature | ≦480℃ |
| Cleaning method | back flushing, ultrasonic or other non-abrasive cleaning |
| Maximum Operating Pressure differential | 4.0bar |
1. Excellent mechanical strength.
2. High dirt holding capacity.
3. High pressure resistance, withstand capacity and low pressure drop.
4. Temperature ratings from -73°C to 480°C.
5. Various micron ratings available from 2um to 1000um nominal.
6. Back flushing and cleanable for long service life.
7. Strong corrosion resistant for wide chemical compatibility.
8. High permeability, no media migration.
9. Customized dimension are welcome.
Stainless steeel Filter Cartridge Applications:
1. Water filtrations
2. Hydraulics
3. Automotive
4. Pneumatics
5. Chemical
6. Petrochemical
7. Medical
8. Oil & gas
9. Aeronautical
10. Mining
11. Food & beverage
12. Pharmaceutical
Our Workshop
